D-Link DWL-2600AP User Manual

Port Access Control
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 421
D-Link UWS User Manual
• If you change the mode, click Submit to apply the new settings to the system.
Port Configuration
Use the Port Access Control Port Configuration page to enable and configure port access control on one or
more ports.
To access the Port Based Access Control Port Configuration page, click LAN > Security > Port Access Control >
Port Configuration in the navigation menu.
Figure 292: Port Access Control Port Configuration
Dynamic VLAN Creation Mode Select Enable to allow the switch to dynamically create a RADIUS-assigned
VLAN if it does not already exist in the VLAN database.
Monitor Mode Select Enable to permit network access even when the 802.1X authentication
process fails. The switch logs the results of the authentication process for
diagnostic purposes.
Monitor Mode can help you troubleshoot Dot1X configuration problems
without affecting network access for end users.
Table 247: Global Port Access Control Configuration Fields (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
