D-Link DWL-2600AP User Manual

RADIUS Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 417
D-Link UWS User Manual
If at least one RADIUS accounting server is configured on the switch, and a host address is selected in the
Accounting Server Host Address field, then additional fields are available on the Accounting Server
Configuration page.
Figure 287: RADIUS Accounting Server Configuration—Server Added
Use the buttons at the bottom of the page to perform the following actions:
• If you make changes to the page, click Submit to apply the changes to the system.
• To delete a configured RADIUS accounting server, select the IP address of the server from the RADIUS
Server IP Address drop-down menu, and then click Remove.
• Click Refresh to update the page with the most current information.
Table 245: RADIUS Accounting Server Configuration Fields
Field Description
Accounting Server Host
Address
Use the drop-down menu to select the IP address of the accounting server to
view or configure. Select Add to configure additional RADIUS servers.
Port Identifies the authentication port the server uses to verify the RADIUS
accounting server authentication. The port is a UDP port, and the valid range
is 1-65535. The default port for RADIUS accounting is 1813.
Secret Specifies the shared secret to use with the specified accounting server. This
field is only displayed if you are logged into the switch with READWRITE
access.
Apply The Secret will only be applied if this box is checked. If the box is not checked,
anything entered in the Secret field will have no affect and will not be
retained. This field is only displayed if you are logged into the switch with
READWRITE access.
Secret Configured Indicates whether the shared secret for this server has been configured.
RADIUS Accounting Server
Name
Enter the name of the RADIUS accounting server.
The name can contain up to 32 alphanumeric characters. Spaces, hyphens,
and underscores are also permitted. If you do not assign a name, the server is
assigned the default name Default-RADIUS-Server.
You can use the same name for multiple RADIUS accounting servers. RADIUS
clients can use accounting servers with the same name as backups for each
other.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
