Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 457
D-Link UWS User Manual
Table 262 describes the fields available on the AP Hardware Capabilities page.
AP Hardware Radio Capability
Use the Radio Detail tab under the Hardware Capabilities tab to view radio details.
Figure 308: Radio Detail
Table 263 on page 457 describes the fields available on the AP Hardware Radio Capability page.
Table 262: AP Hardware Capability Summary
Field Description
Hardware Type Identifies the ID number assigned to each AP hardware type. The switch supports up to six
different AP hardware types.
Hardware Type
Description
Includes a description of the platform and the supported IEEE 802.11 modes.
Radio Count Specifies whether the hardware supports one radio or two radios.
Image Type Specifies the type of software the hardware requires.
Table 263: AP Hardware Capability Radio Detail
Field Description
AP Selector Use the drop-down menu to select the AP model.
Radio Selector If the selected AP is a dual-radio AP, select Radio-1 or Radio-2 to view information
about the selected radio.
Radio Count Displays the number of radios supported on the hardware platform, which is
either 1 or 2.
Radio Type Description Displays the type of radio, which might contain information such as the
manufacturer name and supported IEEE 802.11 modes.
VAP Count Displays the number of VAPs the radio supports.
802.11a Support Shows whether support for IEEE 802.11a mode is enabled.
802.11bg Support Shows whether support for IEEE 802.11bg mode is enabled.
802.11n Support Shows whether support for IEEE 802.11n mode is enabled.
802.11ac Support Shows whether support for IEEE 802.11ac mode is enabled.
