D-Link DWL-2600AP User Manual

Authentication List Summary
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 84
D-Link UWS User Manual
Authentication List Summary
Use the Authentication List Summary page to view information about the authentication lists on the system
and which users are associated with each list. The page also displays information about 802.1X port security
users.
To access the Authentication List Summary page, click LAN > Monitoring > Authentication List Summary in the
navigation tree.
Figure 20: Login Session
The Authentication List Summary page has the following fields:
Table 15: Login Fields
Field Description
Login Authentication List Displays all login authentication profiles
Method List Shows the order of the login methods configured for the list. Possible options
are:
• Enable: uses the enable password for authentication.
• Line: uses the Line password for authentication.
• Local:- the user's locally stored ID and password will be used for
authentication
• None: the user is not authenticated
• Radius: the user's ID and password will be authenticated using the RADIUS
server instead of locally
• TACACS+: the user's ID and password will be authenticated using the
TACACS+ server
Remove Removes the authentication profile when checked.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
