D-Link DWL-2600AP User Manual

Managing the DHCP Server
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 136
D-Link UWS User Manual
Pool Options
Use the Pool Options page to configure DHCP options that the DHCP server can pass to the client. For more
information about DHCP options, see RFC 2132.
To access the Pool Options page, click LAN > Administration > DHCP Server > Pool Options in the navigation
menu.
If no DHCP pools exist, the Pool Options page does not display the fields shown in Figure 58.
Figure 58: Pool Options
If any DHCP pools are configured on the system, the Pool Options page contains the following fields:
To delete an option code for the selected Pool, enter the option code in the folder and click Delete. This button
is not visible to a user with read-only permission.DHCP Server Summary
Table 50: Pool Options Fields
Field Description
Pool Name Select the DHCP pool to with the options you want to view or configure.
Option Code Displays the DHCP option code configured for the selected Pool.
ASCII Value Specifies the Option ASCII Value for the selected pool
Hex Value Specifies the Option Hex Value for the selected pool.
IP Address Value Specifies the Option IP Address Value for the selected pool.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
