Configuring GARP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 206
D-Link UWS User Manual
GARP Switch Configuration
Use the GARP Switch Configuration page to configure GARP settings for the system.
To access the GARP Switch Configuration page, click LAN > L2 Features> GARP > Switch Configuration in the
navigation tree.
Figure 115: GARP Switch Configuration
If you make any changes to the page, click Submit to apply the changes to the system.
Table 99: GARP Switch Configuration Fields
Field Description
Switch GVRP Mode Shows the GARP VLAN Registration Protocol administrative mode for the
switch. The switch GVRP mode must be enabled for the ports to function in
GARP protocols, even if GVRP is enabled on a port.
Switch GMRP Mode Shows the GARP Multicast Registration Protocol administrative mode for the
switch. The switch GMRP mode must be enabled for the ports to function in
GARP protocols, even if GMRP is enabled on a port.
