Configuring and Viewing ISDP Information
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 150
D-Link UWS User Manual
Cache Table
From the ISDP Cache Table page, you can view information about other devices the switch has discovered
through the ISDP. To access the ISDP Cache Table page, click LAN > Monitoring > ISDP > Cache Table in the
navigation menu.
Figure 71: ISDP Cache Table
The following table describes the fields available on the ISDP Cache Table page.
Device ID Format
Capability
Indicates the Device ID format capability of the device.
• serialNumber—Indicates that the device uses serial number as the format for its
Device ID.
• macAddress—Indicates that the device uses layer 2 MAC address as the format for
its Device ID.
• other—Indicates that the device uses its platform specific format as the format for
its Device ID.
Device ID Format Indicates the Device ID format of the device.
• serialNumber—Indicates that the value is in the form of an ASCII string containing
the device serial number.
• macAddress—Indicates that the value is in the form of Layer 2 MAC address.
• other—Indicates that the value is in the form of a platform specific ASCII string
containing info that identifies the device. For example: ASCII string contains
serialNumber appended/prepended with system name.
Table 63: ISDP Cache Table
Field Description
Device ID Displays the string with Device ID which is reported in the most recent ISDP
message.
Interface Displays the interface that this neighbor is attached to.
IP Address The (first) network-layer address that is reported in the Address TLV of the
most recently received ISDP message.
Version Displays the Version string for the neighbor.
Table 62: ISDP Global Configuration
Field Description
