Configuring GARP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 207
D-Link UWS User Manual
GARP Port Configuration
Use the GARP Port Configuration page to configure GARP settings for a specific interface.
To access the GARP Port Configuration page, click LAN > L2 Features> GARP > Port Configuration in the
navigation tree.
Figure 116: GARP Port Configuration
Table 100: GARP Port Configuration Fields
Field Description
Slot/Port Specifies interface on which to configure the GARP settings. If you select All
from the drop-down menu, the settings on the page affect all interfaces.
Port GVRP Mode Choose the GARP VLAN Registration Protocol administrative mode for the
port by selecting enable or disable from the pulldown menu.If you select
disable, the protocol will not be active and the Join Time, Leave Time and
Leave All Time will have no effect. The factory default is disable.
Port GMRP Mode Choose the GARP Multicast Registration Protocol administrative mode for the
port by selecting enable or disable from the pulldown menu. If you select
disable, the protocol will not be active, and Join Time, Leave Time and Leave
All Time have no effect. The factory default is disable.
GARP Timers
GARP Join Timer (centisecs) Specify the time between the transmission of GARP PDUs registering (or re-
registering) membership for a VLAN or multicast group in centiseconds. Enter
a number between 10 and 100 (0.1 to 1.0 seconds). The factory default is 20
centiseconds (0.2 seconds). An instance of this timer exists for each GARP
participant for each port.
