D-Link DWL-2600AP User Manual

Configuring ARP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 289
D-Link UWS User Manual
ARP Create
Use the ARP Create page to add an entry to the Address Resolution Protocol table.
To display the page, click LAN > L3 Features > ARP > ARP Create in the navigation tree.
Figure 184: ARP Create
• After you enter an IP address and the associated MAC address, click Submit to apply the changes to the
system and create the entry in the ARP table.
Table 167: ARP Create Fields
Field Description
IP Address Enter the IP address you want to add. It must be the IP address of a device on
a subnet attached to one of the switch's existing routing interfaces.
MAC Address The unicast MAC address of the device. Enter the address as six two-digit
hexadecimal numbers separated by colons, for example 00:06:29:32:81:40.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
