Configuring Differentiated Services
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 353
D-Link UWS User Manual
Click Refresh to update the information on the screen.
Table 210: Service Detailed Statistics Fields
Field Description
Counter Mode
Selector
Selects the format of the displayed counter values, which must be either Octets or Packets.
The default is Octets.
Interface List of all valid slot number and port number combinations in the system that have a
DiffServ policy currently attached in the In direction.
Direction Selects the direction of packets for which service statistics are to display. Only shows the
direction(s) for which a DiffServ policy is currently attached.
Policy Name Displays the policy currently attached to the selected interface and direction.
Operational
Status
Displays the operational status of the policy currently attached to the specified interface
and direction. The value is either Up or Down.
Member Classes List of all DiffServ classes currently defined as members of the selected Policy Name.
Choose one member class name at a time to display its statistics. If no class is associated
with the chosen policy, then nothing will be populated in the list.
Offered Packets/
Octets
Displays the count of the packets/octets offered to this class instance before the defined
DiffServ treatment is applied.
Discarded
Packets/Octets
Displays the count of packets/octets discarded for this class instance for any reason due to
DiffServ treatment of the traffic class.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
