Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 528
D-Link UWS User Manual
Radio Resource Measurement Status Information
The Radio Resource Measurement (RRM) feature enables the Wireless System to provide information to the
wireless clients to help them make roaming decisions. The RRM feature also enables the Wireless system to
gather information from wireless clients.
The RRM feature implements a subset of the radio resource measurement capabilities defined by the IEEE
802.11k standard.
Viewing the RRM Channel Load Configuration
The RRM Channel Load Configuration page allows you to ask a client to measure utilization on a specified
channel for a specified duration. The page displays the results of the currently loaded channel.
The Channel Load feature is intended for network debugging. The Wireless System does not take any
automatic actions based on the reported channel utilization.
Figure 348: RRM Channel Load Configuration
The following table describes the fields on the RRM Channel Load Configuration page.
Table 316: RRM Channel Load Configuration
Field Description
Current Request Status
Client MAC Address Shows the MAC Address of the client with the channel load currently being
measured.
Channel Shows the channel the client uses to measure the load.
Measurement Duration Number of time units (TUs) for which to measure the channel. Each TU is equal to
1024 μs.
