D-Link DWL-2600AP User Manual

Configuring MLD Snooping
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 233
D-Link UWS User Manual
Multicast Router VLAN Status
Use the MLD Snooping Multicast Router VLAN Status page to view multicast router settings for VLANs on a
specific interface.
To access the MLD Snooping Multicast Router VLAN Statistics page, click Monitoring > MLD Snooping >
Multicast Router VLAN Status in the navigation tree.
Figure 138: MLD Snooping Multicast Router VLAN Status
The MLD Snooping Multicast Router VLAN Statistics page contains the following fields:
• Click Refresh to re-display the page with the latest information from the router.
Table 122: MLD Snooping Multicast Router VLAN Status Fields
Description
Slot/Port Select the physical or LAG interface to display.
VLAN ID If a VLAN is enabled for multicast routing on the interface, this field displays its ID.
Multicast Router Indicates that the multicast router is enabled for the VLAN on this interface.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
