D-Link DWL-2600AP User Manual

Configuring DNS
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 147
D-Link UWS User Manual
DNS Host Name IP Mapping Configuration
Use this page to configure DNS host names for hosts on the network. The host names are associated with IPv4
or IPv6 addresses on the network, which are statically assigned to particular hosts.
To access this page, click LAN > Administration > DNS Client > HostName IP Mapping in the navigation tree,
then click the Add Static Entry button.
Figure 68: DNS Host Name Mapping Configuration
• Click Submit to apply the new configuration and cause the change to take effect immediately. These
changes will not be retained across a power cycle unless a Save is performed.
• Click Back to cancel and display the hostname IP mapping page to see the configured hostname-IP
mapping entries.
Table 60: DNS Host Name Mapping Configuration Fields
Field Description
Host Name Enter the host name to assign to the static entry.
Inet Address Enter the IP4 or IPv6 address associated with the host name.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
