Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 513
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
Viewing Detailed Associated Client Session Statistics
The statistics on the WLAN > Monitoring > Client > Associated Clients > Statistics > Session Detail page show
information about the traffic a wireless client receives and transmits while it is connected to the same WLAN
network shared by APs that the switch manages. Use the menu above the table to view details about an
associated client. Each client is identified by its MAC address.
Figure 337: Associated Client Session Detail Statistics
Duplicates Received Total duplicate packets received from the client station.
Table 305: Associated Client Session Detail Statistics
Field Description
Packets Received Total packets received from the client station.
Bytes Received Total bytes received from the client station.
Packets Transmitted Total packets transmitted to the client station.
Bytes Transmitted Total bytes transmitted to the client station.
Packets Receive Dropped Number of packets received from the client station that were dropped.
Bytes Receive Dropped Number of bytes received from the client station that were dropped.
Packets Transmit Dropped Number of packets transmitted to the client station that were
dropped.
Bytes Transmit Dropped Number of bytes transmitted to the client station that were dropped.
Table 304: Associated Client Association Detail Statistics (Cont.)
Field Description
