Managing LLDP
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 259
D-Link UWS User Manual
Global Configuration
Use the LLDP Global Configuration page to specify LLDP parameters that are applied to the switch.
To display the LLDP Global Configuration page, click LAN > L2 Features > LLDP > Global Configuration in the
navigation tree.
Figure 158: LLDP Global Configuration
If you make any changes to the page, click Submit to apply the new settings to the system.
Table 141: LLDP Global Configuration Fields
Field Description
Transmit Interval Specifies the interval at which LLDP frames are transmitted. The default is 30
seconds, and the valid range is 5-32768 seconds.
Transmit Hold Multiplier Specifies multiplier on the transmit interval to assign to TTL. The default is 4,
and the range is 2-10.
Re-Initialization Delay Specifies the delay before a re-initialization. The default is 2 seconds, and the
range is 1-10 seconds.
Notification Interval Limits the transmission of notifications. The default is 5 seconds, and the
range is 5-3600 seconds.
