D-Link DWL-2600AP User Manual

AP Management
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 583
D-Link UWS User Manual
Access Point Software Download
The DWS-4000 Series switch can upgrade software on the APs that it manages. The Cluster Controller can
update code on the APs that it manages as well as APs managed by peer wireless switches.
To upgrade one or more AP from the switch that manages it, click the WLAN > Administration > AP
Management > Software Downloads tab.
Figure 373: Software Download
After you provide the information about the upgrade file, as described in the following table, click Start to
begin the upgrade process. Additional fields appear after the download begins and provide information about
upgrade status and success.
Note: The APs automatically reset after the code is successfully downloaded and installed.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
