D-Link DWL-2600AP User Manual

Captive Portal Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 387
D-Link UWS User Manual
Changing the Captive Portal Settings
By default, the switch has one captive portal. You can change the settings for that captive portal, and you can
also create and configure up to nine additional portals. After you create a captive portal from the CP Summary
page, you can change its settings.
Figure 261: Captive Portal Configuration
Table 225 describes the fields on the CP Configuration page.
Protocol Indicates whether the portal uses HTTP or HTTPS.
Verification Specifies which type of user verification to perform:
• Guest: The user does not need to be authenticated by a database.
• Local: The switch uses a local database to authenticated users.
• RADIUS: The switch uses a database on a remote RADIUS server to authenticate
users.
To configure authorized users on the local or remote RADIUS database, see “Local User”
on page 395.
Languages Shows the number of languages that are configured for this captive portal.
Table 225: CP Configuration
Field Description
Enable Captive
Portal
Select the check box to enable the CP. Clear the check box to disable it.
Table 224: Captive Portal Summary (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
