Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 481
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
WLAN Bytes Receive Dropped Number of bytes received by the AP on the wireless network that
were dropped.
WLAN Packets Transmit Dropped Number of packets transmitted by the AP on the wireless network
that were dropped.
WLAN Bytes Transmit Dropped Number of bytes transmitted by the AP on the wireless network that
were dropped.
Ethernet Packets Received Total packets received by the AP on the wired network.
Ethernet Bytes Received Total bytes received by the AP on the wired network.
Ethernet Packets Transmitted Total packets transmitted by the AP on the wired network.
Ethernet Bytes Transmitted Total bytes transmitted by the AP on the wired network.
Multicast Packets Received Total multicast packets received by the AP on the wired network.
Total Receive Errors Total receive errors detected by the AP on the wired network.
Total Transmit Errors Total transmit errors detected by the AP on the wired network.
ARP Reqs Converted from Bcast to
Ucast
Number of ARP requests that the AP converted from a broadcast
packet to a unicast packet before sending to the wireless link.
Filtered ARP Requests Number of ARP requests that AP was able to drop instead of sending
on the wireless link.
Broadcasted ARP Requests The number of ARP requests sent as broadcasts on the VAPs. This
counter does not include WDS links. The same ARP frame may be
counted multiple times when it is broadcasted on multiple VAPs. The
counter is available even when ARP suppression is disabled.
TSPEC Statistics (Voice and Video)
Total TSPEC Packets Received The number of TSPEC packets sent from the wireless client to the AP.
Total TSPEC Packets Transmitted The number of TSPEC packets sent from the AP to the wireless client.
Total TSPEC Bytes Received The number of TSPEC bytes sent from the wireless client to the AP.
Total TSPEC Bytes Transmitted The number of TSPEC bytes sent from the AP to the wireless client.
Total TSPECs Accepted The number of TSPEC packets that were accepted by the AP.
Total TSPECs Rejected The number of TSPEC packets that were rejected by the AP.
Total Roaming TSPECs Accepted The total number of TSPEC packets transmitted by roaming clients
that were accepted by the AP.
Total Roaming TSPECs Rejected The total number of TSPEC packets transmitted by roaming clients
that were rejected by the AP.
Table 281: Detailed Managed Access Point Statistics (Cont.)
Field Description
