D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 448
D-Link UWS User Manual
Maximum AP
Provisioning Entries
Number of AP provisioning entries that can be stored by the system.
RRM Channel Load
History Entries
Current number of RRM channel load history entries in use by the system.
Maximum Channel
Load History Entries
Number of channel load history entries that can be stored by the system.
WLAN Bytes
Transmitted
Total bytes transmitted across all APs managed by the switch.
WLAN Packets
Transmitted
Total packets transmitted across all APs managed by the switch.
WLAN Bytes Received Total bytes received across all APs managed by the switch.
WLAN Packets
Received
Total packets received across all APs managed by the switch.
WLAN Bytes Transmit
Dropped
Total bytes transmitted across all APs managed by the switch that were dropped.
WLAN Packets
Transmit Dropped
Total packets transmitted across all APs managed by the switch that were dropped.
WLAN Bytes Receive
Dropped
Total bytes received across all APs managed by the switch that were dropped.
WLAN Packets Receive
Dropped
Total packets received across all APs managed by the switch that were dropped.
Distributed Tunnel
Packets Transmitted
Total number of packets sent by all APs via distributed tunnels.
Distributed Tunnel
Roamed Clients
Total number of clients that successfully roamed away from Home AP using
distributed tunneling.
Distributed Tunnel
Clients
Total number of clients that are associated with an AP that are using distributed
tunneling.
Distributed Tunnel
Client Denials
Total number of clients for which the system was unable to set up a distributed
tunnel when client roamed.
Total Voice Traffic
Streams
Shows the number of voice traffic streams being transmitted by wireless clients that
are connected to the network through APs managed by this switch.
Note: A traffic stream is a collection of data packets identified by the AP as belonging
to a particular user priority.
Total Video Traffic
Streams
Shows the number of video traffic streams being transmitted by wireless clients that
are connected to the network through APs managed by this switch.
Total Traffic Stream
Clients
Shows the number of wireless clients currently transmitting traffic streams.
Total Traffic Stream
Roaming Clients
Shows the number of wireless clients with a roaming status that are currently
transmitting traffic streams.
Table 258: Global WLAN Status/Statistics (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
