Viewing System Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 164
D-Link UWS User Manual
Packets Received > 1522
Octets
The total number of packets received that were longer than 1522 octets
(excluding framing bits, but including FCS octets) and were otherwise well
formed.
Packets Received Successfully
Total Packets Received
Without Errors
The total number of packets received that were without errors.
Unicast Packets Received The number of subnetwork-unicast packets delivered to a higher-layer
protocol.
Multicast Packets Received The total number of good packets received that were directed to a multicast
address. Note that this number does not include packets directed to the
broadcast address.
Broadcast Packets Received The total number of good packets received that were directed to the
broadcast address. Note that this does not include multicast packets.
Packets Received with MAC Errors
Total Packets Received with
MAC Errors
The total number of inbound packets that contained errors preventing them
from being deliverable to a higher-layer protocol.
Jabbers Received The total number of packets received that were longer than 1518 octets
(excluding framing bits, but including FCS octets), and had either a bad Frame
Check Sequence (FCS) with an integral number of octets (FCS Error) or a bad
FCS with a non-integral number of octets (Alignment Error). Note that this
definition of jabber is different than the definition in IEEE-802.3 section
8.2.1.5 (10BASE5) and section 10.3.1.4 (10BASE2). These documents define
jabber as the condition where any packet exceeds 20 ms. The allowed range
to detect jabber is between 20 ms and 150 ms.
Fragments Received The total number of packets received that were less than 64 octets in length
with ERROR CRC (excluding framing bits but including FCS octets).
Undersize Received The total number of packets received that were less than 64 octets in length
with GOOD CRC (excluding framing bits but including FCS octets).
Alignment Errors The total number of packets received that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with a non-integral number of octets.
Rx FCS Errors The total number of packets received that had a length (excluding framing
bits, but including FCS octets) of between 64 and 1518 octets, inclusive, but
had a bad Frame Check Sequence (FCS) with an integral number of octets
Overruns The total number of frames discarded as this port was overloaded with
incoming packets, and could not keep up with the inflow.
Total Ignored Frames The total number of dropped packets including those that were aborted.
Total Deferred Frames The total number of frames that could not be transmitted after multiple
attempts because they encountered collisions.
Received Packets Not Forwarded
Total Received Packets Not
Forwarded
A count of valid frames received which were discarded (i.e., filtered) by the
forwarding process.
Local Traffic Frames The total number of frames dropped in the forwarding process because the
destination address was located off of this port.
Table 72: Detailed Port Statistics Fields (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
