Page #394 background image
Captive Portal Configuration
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 394
D-Link UWS User Manual
Denied Message Enter the text to display when the user does not provide valid authentication
information. This message displays after the user clicks the button to connect to the
network.
Resource Message Enter the text to display when the system has rejected authentication due to system
resource limitations. This message displays after the user clicks the button to connect to
the network.
Timeout Message Enter the text to display when the system has rejected authentication because the
authentication transaction took too long. This could be due to user input time, or a
timeout due to the overall transaction.
Busy Message Enter the text to display when the Captive Portal is processing the authentication
request. This message displays after the user clicks the button to connect to the network.
No Accept Message Enter the text to display when the user did not accept the acceptance use policy. This
message displays after the user clicks the button to connect to the network.
Welcome Page
Background Image Shows the name of the current background image on the Welcome Page. This field can
be modified from the CP WEB Customization Global Parameters page.
Branding Image Shows the name of the current branding image on the Welcome Page. This field can be
modified from the CP WEB Customization Global Parameters page.
Welcome Title Enter the title to display to greet the user after he or she successfully connects to the
network.
Welcome Text Enter the optional text to display to further identify the network to be access by the CP
user. This message displays under the Welcome Title.
Logout Page
Note: The fields on this page are only applicable when the User Logout Mode is enabled, but you can modify
the fields whether the feature is enabled or disabled.
Browser Title Enter the text to display on the title bar of the Logout page.
Page Title Enter the text to use as the page title. This is the text that identifies the page.
Instructional Text Enter the detailed text to display that confirms that the user has been authenticated and
instructs the user how to deauthenticate.
Button Label Enter the text to display on the button the user clicks to deauthenticate.
Confirmation Text Enter the detailed text to display that prompts users to confirm the deauthentication
process.
Logout Success Page
Note: The fields on this page are only applicable when the User Logout Mode is enabled, but you can modify
the fields whether the feature is enabled or disabled.
Background Image Shows the name of the current background image on the Logout Success page. This field
can be modified from the CP WEB Customization Global Parameters page.
Branding Image Shows the name of the current branding image on the Logout Success page. This field
can be modified from the CP WEB Customization Global Parameters page.
Browser Title Enter the text to display on the title bar of the Logout Success page.
Title Enter the text to use as the page title. This is the text that identifies the page.
Content Enter the text to display that confirms that the user has been deauthenticated.
Table 226: CP Web Page Customization
Field Description
