D-Link DWL-2600AP User Manual

Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 454
D-Link UWS User Manual
Command Buttons
The page includes the following button:
• Refresh—Updates the page with the latest information.
IP Address Shows the IP address of the device configured in the IP Discovery list.
Status The status is in one of the following states:
• Not Polled: The switch has not attempted to contact the IP address in the L3/
IP Discovery list.
• Polled: The switch has attempted to contact the IP address.
• Discovered: The switch contacted the peer switch or the AP in the L3/IP
Discovery list and has authenticated or validated the device.
• Discovered - Failed: The switch contacted the peer switch or the AP with IP
address in the L3/IP Discovery list and was unable to authenticate or validate
the device.
If the device is an access point, an entry appears in the AP failure list with a failure
reason.
Table 260: AP Hardware Capability Radio Detail (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
