Monitoring Status and Statistics
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 534
D-Link UWS User Manual
Command Buttons
The page includes the following buttons:
• Refresh — Updates the page with the latest information.
• Apply Password — Apply the password in the New WDS Group Password field to members of the WDS
group.
Satellite AP Count Number of satellite APs currently being managed by the switch that are members of
this WDS AP group.
Root Bridge AP MAC MAC Address of the device elected as the Spanning Tree Root Bridge. If spanning tree
is disabled this value is 00:00:00:00:00:00.
Root Device Type The type of device elected as the Spanning Tree Root bridge:
• None ( is disabled)
• Root AP
• Satellite AP
• External Device ( Root is not one of the APs)
Config WDS Link Count Number of configured bidirectional links in the WDS AP group.
Detect WDS Links
Count
Number of WDS links detected in the system. APs on both sides of the link must
detect each other in order for the link to be counted.
Blocked WDS Link
Count
Number of WDS links blocked by the spanning tree protocol. If the AP on one side of
the link reports the link as blocking then the link is counted by this status parameter.
WDS Group Password
Change Status
Status of the last attempt to configure the password for the WDS group:
• Not Started
• Success
• Invalid Password
• Requested
• Timed Out
New WDS Group
Password
To change the password for all switches and APs in this WDS group, select the Edit
checkbox, type the new password, and then click Apply Password.
Table 320: WDS AP Group Status (Cont.)
Field Description
