D-Link DWL-2600AP User Manual

Configuring Advanced Settings
D-Link Unified Wired and Wireless Access System
Oct. 2015 Page 620
D-Link UWS User Manual
Command Buttons
The page includes the following buttons:
• Refresh—Updates the page with the latest information.
• Submit—Updates the switch with the values you enter. To retain the new values across a power cycle,
you must perform a save (Tool > Save Changes).
Network Use the option to the left of the network to enable or disable the corresponding VAP
on the selected radio.
When enabled, use the menu to select a networks to assign to the VAP. You can
configure up to 64 separate networks on the switch and apply them across multiple
radio and VAP interfaces. By default, 16 networks are pre-configured and applied in
order to the VAPs on each radio.
Enabling a VAP on one radio does not automatically enable it on the other radio.
Note: You cannot disable the default VAP, VAP0.
Note: The IEEE 802.11n standard prohibits static WEP and dynamic WEP
(IEEE802.1X) security modes. Additionally, 802.11n requires the CCMP(AES) WPA
cypher to be enabled. If the AP profile includes the 802.11n radio mode, you cannot
select a configured network from the Network menu if the network uses static or
dynamic WEP as the security method or if the CCMP(AES) WPA cypher is not
enabled.
To configure additional networks, click Advanced Configuration > Networks.
Edit Click Edit to modify settings for the corresponding network.
When you click Edit, the Wireless Network Configuration page appears.
VLAN Shows the VLAN ID of the VAP. To change this setting, click Edit.
L3 Tunnel Shows whether L3 Tunneling is enabled on the network.
Note: When L3 tunneling is enabled, the VLAN ID configured above is not used. In
fact, the switch puts the management VLAN ID, if any, on the tunneled packets
destined to the AP.
Hide SSID Shows whether the VAP broadcasts the SSID. If enabled, the SSID for this network is
not included in AP beacons. To change this setting, click Edit.
Security Shows the current security settings for the VAP. To change this setting, click Edit.
Redirect Shows whether HTTP redirect is enabled. The possible values for the field are as
follows:
• HTTP: HTTP Redirect is enabled
• None: HTTP Redirect is disabled
Table 356: Default VAP Configuration (Cont.)
Field Description

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
