D-Link DWL-2600AP

Configuring VLANs
D-Link Unified Wired and Wireless Access System
July 2012 Page 681
D-Link UWS User Manual
tagged from ports that are members of VLAN 2.
9. Click Submit.
10. Select VLAN 3 from the VLAN ID and Name List.
11. Select the Participate option in the VLAN field.
12. For ports 0/2, 0/3 and 0/4, select Include from the Participation menu to specify that these ports are
members of VLAN 3.
13. Click Submit.
14. Go to the LAN > L2 Features > VLAN > Port Configuration page.
15. From the Slot/Port menu, select 0/1.
16. In the Acceptable Frame Types field, select VLAN Only to specify that untagged frames will be rejected on
receipt.
17. Click Submit.
18. From the Slot/Port menu, select 0/2.
19. In the Port VLAN ID field, enter 3 to assign VLAN 3 as the default VLAN for the port.
20. In the Acceptable Frame Types field, select VLAN Only to specify that untagged frames will be rejected on
receipt.
21. Click Submit.
