Diagnostics Analyze network traffic
IX20 User Guide
1097
Configure packet capture for the network analyzer
To use the network analyzer, you must create one or more packet capture configuration.
Required configuration items
n
The interface used by thispacket capture configuration.
Additional configuration items
n
The filter expression for this packet capture configuration.
n
Schedule the analyzer to run based on aspecified event or at a particular time:
l
The eventsor time that will trigger the analyzer to run, using this capture configuration.
l
The amount of time that the analyzer session will run.
l
The frequency with which captured events will be saved.
To configure a packet capture configuration:
Web
1. Log into Digi Remote Manager, or log into the local Web UI asa user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
