Digi IX20 User Manual

Virtual PrivateNetworks(VPN) L2TPv3 Ethernet
IX20 User Guide
627
3. To display details about a specific tunnel:
> show l2tp lac name lac_test2
lac_test2 L2TP Access Concentrator Status
------------------------------------
Enabled : true
Status : pending
>
4. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Show the statusof L2TP network serversfrom the Admin CLI
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. To display details about all configured L2TPaccessconnectors, type the following at the
prompt:
> show l2tp lns
Name Enabled Status Device
--------- ------- ------ -----------
lns_test1 true up test_device0
lns_test2 true pending
>
3. To display details about a specific tunnel:
> show l2tp lns name lns_test2
lns_test2 L2TP Access Concentrator Status
------------------------------------
Enabled : true
Status : pending
>
4. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
L2TPv3 Ethernet
Your IX20 device supportsLayer 2Tunneling Protocol Version 3 (L2TPv3) static unmanaged Ethernet
tunnels.

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
