Virtual PrivateNetworks(VPN) L2TPv3 Ethernet
IX20 User Guide
632
13. (Optional) Set the cookie value of the remote peer:
(config vpn l2tpeth L2TPv3_example session_example)> peer cookie value
(config vpn l2tpeth L2TPv3_example session_example)>
Allowed value is 8 or 16 hex digits.
14. Set the Layer2Specific header type. This must match what is configured on the remote peer.
(config vpn l2tpeth L2TPv3_example session_example)> l2spec_type value
(config vpn l2tpeth L2TPv3_example session_example)>
where value is either none or default. The default is default.
15. Set the sequence number control to prevent or detect out of order packets.
(config vpn l2tpeth L2TPv3_example session_example)> seq value
(config vpn l2tpeth L2TPv3_example session_example)>
where value is one of:
n
none: No sequence numbering.
n
send: Add a sequence number to each outgoing packet.
n
recv: Reorder packets if they are received out of order.
n
both: Add a sequence number to each outgoing packet, and reorder packets if they are
received out of order.
The default is none.
16. Save the configuration and apply the change
(config)> save
Configuration saved.
>
17. Typeexit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Show L2TPV3 tunnel status
Web
Log into the IX20 WebUI asa user with full Admin accessrights.
1. On the menu, select Status. Under VPN, select L2TPv3 Ethernet.
The L2TPv3 Ethernet page appears.
2. To view configuration details about an L2TPV3 tunnel, click the (configuration) icon in the
upper right of the tunnel's statuspane.
Command line
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
