Virtual PrivateNetworks(VPN) L2TP
IX20 User Guide
615
7. Configure the overlay connection using BGP:
a. Type ... to return to the top level of the configuration schema:
(config network interface dmvpn_tunnel_interface)> ...
(config)>
b. Enable BGP:
(config)> network route service bgp enable true
(config)>
c. Set the autonomoussystem number for this device. For example, to set the autonomous
system number to 66007:
(config)> network route service bgp asn 66007
(config)>
d. Set the best path criteria to multipath:
(config)> network route service bgp as_path multipath-relax
(config)>
e. Add a neighbour:
(config)> add network route service bgp neighbour end
(config network route service bgp neighbour 0)>
f. Set ip to the IPaddressof the hub. For example:
(config network route service bgp neighbour 0)> ip 10.20.1.1
(config network route service bgp neighbour 0)>
g. Enable eBGPmultihop:
(config network route service bgp neighbour 0)> ebgp_multihop true
(config network route service bgp neighbour 0)>
8. Repeat to add additional spokes.
9. Save the configuration and apply the change
(config)> save
Configuration saved.
>
10. Typeexit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
L2TP
Your IX20 device supportsPPP-over-L2TP(Layer 2Tunneling Protocol).
