Serial port ConfigurePPPdial-in mode
IX20 User Guide
270
Configure PPP dial-in mode
PPP dial-in allowsthe device to answer Point-to-Point Protocol (PPP) connectionsover serial ports.
To change the configuration to match the serial configuration of the device to which you want to
connect:
Web
1. Log into Digi Remote Manager, or log into the local Web UI asa user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click to expand the name of the port that you want to configure, for example, Port 1.
The serial port is enabled by default. To disable, toggle off Enable.
