Firewall ConfigureQuality of Serviceoptions
IX20 User Guide
961
3. Click Firewall >Captive portals.
4. Click the down caret () next to the appropriate captive portal and select Delete.
5. Click Apply to savethe configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. To delete a captiveportal, use the del command. For example:
(config)> del firewall portal portal1
4. Save the configuration and apply the change
(config)> save
Configuration saved.
>
5. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Configure Quality of Service options
Quality of Service (QoS) optionsallow you to manage the traffic performance of variousservices, such
as Voiceover IP(VoIP), cloud computing, traffic shaping, traffic prioritizing, and bandwidth allocation.
When configuring QOS, you can only control the queue for outgoing packets on each interface(egress
packets), not what is received on the interface (packet ingress).
AQoSbinding contains the policiesand rules that apply to packetsexiting the IX20 device on the
binding's interface. By default, the IX20 device has two preconfigured QoSbindings, Outbound and
Inbound. These bindings are an example configuration designed for a typical VoIPsite:
n
Outbound providesan example of matching packets as they are routed from the device onto
the WAN interface.
