Serial port Configure Application mode
IX20 User Guide
268
n
both
n
arrows. Thisis the default.
e. Log the time at which date was received or transmitted:
(config)>serial port1 logging hex true
(config)>
f. Log data ashexadecimal values:
(config)>serial port1 logging timestamp true
(config)>
17. Save the configuration and apply the change
(config)> save
Configuration saved.
>
18. Typeexit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Configure Application mode
Application mode providesaccess to the serial device from Python applications.
To change the configuration to match the serial configuration of the device to which you want to
connect:
Web
Log into the IX20 WebUI asa user with full Admin accessrights.
1. On the menu, click System. Under Configuration, click Serial Configuration.
The Serial Configuration page is displayed.
Note You can also configure the serial port by using Device Configuration >Serial. Changes
made by using either Device Configuration or Serial Configuration will be reflected in both.
