Digi IX20hardwarereference IX20LEDs
IX20 User Guide
30
Power
Off
No power.
Solid green
Device haspower
INT
Off
The WAN/ETH1 Ethernet port not connected.
Flashing green
The WAN/ETH1 Ethernet port is connecting.
Solid green
The WAN/ETH1 Ethernet port is connected and
has activity.
Wi-Fi Service (IX20Wmodel only)
Off
No Wi-Fi accesspoints or Wi-Fi clientsare
enabled.
Solid green
Wi-Fi accesspoints or Wi-Fi clientsare enabled.
