Interfaces Local Area Networks(LANs)
IX20 User Guide
184
3. Click Network >Interfaces.
4. Create the LAN or select an existing LAN:
n
To create a new LAN, for Add interface, type a name for the LAN and click .
n
To edit an existing LAN, click to expand the LAN.
The Interface configuration window is displayed.
New LANs are enabled by default. To disable, toggle off Enable.
5. For Interface type, leaveat the default setting of Ethernet.
6. For Zone, select the appropriate firewall zone. See Firewall configuration for further
information.
7. For Device, select an Ethernet device, a Wi-Fi access point, or a bridge. See Bridging for more
information about bridging.
8. (Optional) Click to expand 802.1x to configure 802.1x port based network access control.
The IX20 can function as an 802.1x authenticator; it doesnot function as an 802.1x supplicant.
a. Click to expand Authentication.
b. Click Enable server to enable the 802.1x authenticator on the IX20 device.
c. Set the Reauth period.
9. Configure IPv4 settings:
a. Click to expand IPv4.
IPv4 support is enabled by default.
b. For Type, select Static IP address.
