Interfaces Local Area Networks(LANs)
IX20 User Guide
193
6. Save the configuration and apply the change
(config)> save
Configuration saved.
>
7. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Add the WAN/ETH1 Ethernet port to the default LAN bridge
This procedure will add the WAN/ETH1 port to the default LAN bridge, which will configure Ethernet
ports on the device to function asa hub.
To add the WAN/ETH1 port to the LAN bridge:
 Web
1. Log into Digi Remote Manager, or log into the local Web UI asa user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network >Bridges> LAN.
4. Click to expand Devices.
