Digi IX20 User Manual

Serial port ConfigureUDPserial mode
IX20 User Guide
282
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. The serial port is enabled by default. To disable:
(config)> serial port1 enable false
(config)>
4. Set the mode:
(config)> serial port1 mode udp
(config)>
5. (Optional) Set a label that will be used when referring to thisport.
(config)>serial port1 label label
(config)>
6. Set the baud rate used by the device to which you want to connect:
(config)>serial port1 label baudrate rate
(config)>
7. Set the number of data bitsused by the device to which you want to connect:
(config)>serial port1 label databits bits
(config)>
8. Set the typeof parity used by the device to which you want to connect:
(config)>serial port1 label parity parity
(config)>
Allowed values are:
n
even
n
odd
n
none
The default is none.
9. Set the stop bits used by the device to which you want to connect:
(config)>serial port1 label stopbits bits
(config)>
10. Set the typeof flow control used by the device to which you want to connect:
(config)>serial port1 label flow type
(config)

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
