Digi IX20 User Manual

Serial port ConfigureModbusmode
IX20 User Guide
293
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. The serial port is enabled by default. To disable:
(config)> serial port1 enable false
(config)>
4. Set the mode:
(config)> serial port1 mode modbus
(config)>
5. (Optional) Set a label that will be used when referring to thisport.
(config)>path-paramlabel label
(config)>
6.1. Set the baud rate used by the device to which you want to connect:
(config)>serial port1 baudrate rate
(config)>
2. Set the number of data bitsused by the device to which you want to connect:
(config)>serial port1 databits bits
(config)>
3. Set the typeof parity used by the device to which you want to connect:
(config)>serial port1 parity parity
(config)>
Allowed values are:
n
even
n
odd
n
none
The default is none.
4. Set the stop bits used by the device to which you want to connect:
(config)>serial port1 stopbits bits
(config)>

Digi IX20 Specifications

General

Category	Wireless Router
Cellular Connectivity	4G LTE
Ethernet Ports	4
Wi-Fi	802.11ac
SIM Slots	2
WAN Ports	1
LAN Ports	3
Weight	0.5 kg
Operating Temperature	-40°C to +70°C (-40°F to +158°F)
