Routing Virtual Router Redundancy Protocol (VRRP)
IX20 User Guide
456
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
3. Click Network >VRRP.
4. For Add VRRP instance, type a name for the VRRP instance and click .
The new VRRPinstance configuration is displayed.
5. Click Enable.
6. For Interface, select the interface on which this VRRP instance should run.
7. For Router ID field, type the ID of the virtual router instance. The Router IDmust be the same
on all VRRPdevices that participate in the same VRRPdevice pool. Allowed values are from 1
and 255, and it is configured to 50 by default.
8. For Priority, typethe priority for this router in the group. Therouter with the highest priority
will be used as the master router. If the master router fails, then the IPaddressof the virtual
router is mapped to the backup device with the next highest priority. If this device's actual IP
addressis being used as the virtual IPaddressof the VRRPpool, then the priority of this device
should beset to 255 . Allowed valuesare from 1 and 255, and it is configured to 100 by
default.
