Virtual PrivateNetworks(VPN) OpenVPN
IX20 User Guide
575
c. Create a label for the test:
(config vpn openvpn client openvpn_client1 surelink tests 1)> label
string
(config vpn openvpn client openvpn_client1 surelink tests 1)>
d. if the test should apply to both IPv6 rather than IPv4, enable IPv6:
(config vpn openvpn client openvpn_client1 surelink tests 1)> ipv6
true
(config vpn openvpn client openvpn_client1 surelink tests 1)>
e. Set the test type:
(config vpn openvpn client openvpn_client1 surelink tests 1)> test
value
(config vpn openvpn client openvpn_client1 surelink tests 1)>
where value is one of:
n
ping: Uses ICMPto determine connectivity.
If ping is selected, complete the following:
l
Set the ping_method:
(config vpn openvpn client openvpn_client1 surelink tests 1)>
ping_method value
(config vpn openvpn client openvpn_client1 surelink tests 1)>
where value is one of:
o
hostname: The hostname or IPaddress of an external server.
o
Set ping_host to the hostname or IPaddress of the server:
(config vpn openvpn client openvpn_client1 surelink tests
1)> ping_host hostname/IP_address
(config vpn openvpn client openvpn_client1 surelink tests
1)>
o
interface_gateway. If set, an initial traceroute issent to the hostname or IP
addressconfigured in the SureLink advanced settings, and then the first hop
in that route isused for the ping test.
o
interface_address.
o
interface_dns: Theinterface'sDNSserver.
l
Set the number of bytesto send as part of the ping payload:
(config vpn openvpn client openvpn_client1 openvpn client
openvpn_client1 surelink tests 1)> ping_size int
(config vpn openvpn client openvpn_client1 surelink tests 1)>
n
dns: Performsa DNSquery to the named DNSserver.
If dnsis set, set the IPv4 or IPv6 addressof the DNSserver:
