Virtual PrivateNetworks(VPN) Generic Routing Encapsulation (GRE)
IX20 User Guide
596
3. Click VPN >IPsec> Tunnels.
4. For Add IPsecTunnel, type ipsec_gre1 and click .
5. Click to expand Authentication.
6. For Pre-shared key, type testkey.
7. Click to expand Remote endpoint.
8. For Hostname, typepublic IPaddressof the IX20-2device.
9. Click to expand Policies.
10. For Add Policy, click  to add a new policy.
11. Click to expand Local network.
12. For Type, select Custom network.
13. For Address, typethe IPaddress and subnet of the local GREtunnel, 172.30.0.1/32.
14. For Remote network, type the IPaddressand subnet of the remote GREtunnel,
172.30.0.2/32.
15. Click Apply to save the configuration and apply the change.
