Virtual PrivateNetworks(VPN) NEMO
IX20 User Guide
639
12. Click to expand GRE tunnel local endpoint.
a. For Type, select the local endpoint of the GRE endpoint negotiated by NEMO.
n
If Default route is selected, the network interface that is used will be the same as
the default route.
n
If Interface is selected, specify the local network interface.
The default is Default route.
13. Click to expand Local networks.
a. For Add Interface, click to add a local network to use as a virtual NEMOnetwork
interface.
b. For Interface, select the local interfaceto use as a virtual NEMOnetwork interface.
Generally, this will be the a Local Area Network (LAN).
c. (Optional) Repeat for additional interfaces.
14. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a NEMOtunnel. For example, to add a NEMOtunnel named nemo_example:
(config)> add vpn nemo nemo_example
(config vpn nemo nemo_example)>
The NEMOtunnel is enabled by default. To disable:
(config vpn nemo nemo_example)> enable false
(config vpn nemo nemo_example)>
4. Set the IPv4 address of the NEMOvirtual network interface:
(config vpn nemo nemo_example)> home_address IPv4_address
(config vpn nemo nemo_example)>
5. Set the IPv4 address of the NEMOhome agent. Thisis provided by your cellular carrier.
(config vpn nemo nemo_example)> home_agent IPv4_address
(config vpn nemo nemo_example)>
