Firewall ConfigureQuality of Serviceoptions
IX20 User Guide
967
n
IPv4 address: Only traffic destined for the IPaddresstyped in IPv4 address
will be matched. Use the format IPv4_address[/netmask], or use any to match
any IPv4 address.
n
IPv6 address: Only traffic destined for the IPaddresstyped in IPv6 address
will be matched. Use the format IPv6_address[/prefix_length], or use any to
match any IPv6 address.
Repeat to add a new rule. Up to 30 rulescan be configured.
10. Click Apply to save the configuration and apply the change.
Command line
1. Select the device in Remote Manager and click Actions> Open Console, or log into the IX20
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to accessthe Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Add a binding:
(config)> add firewall qos end
(config firewall qos 2)>
New binding are enabled by default. To disable:
(config firewall qos 2)> enable false
(config firewall qos 2)>
4. (Optional) Set a label for the new binding:
(config firewall qos 2)> label my_binding
(config firewall qos 2)>
5. Set the interface to queue egresspackets on. The binding will only match traffic that is being
sent out on this interface:
a. Use the ?to determine available interfaces:
(config firewall qos 2)> interface ?
Interface: The network interface.
Format:
/network/interface/defaultip
/network/interface/defaultlinklocal
/network/interface/eth1
/network/interface/eth2
/network/interface/loopback
Current value:
