275
7.9 SIGMA stitching exposure
Chapter 7
Number Name Functions
(5) Reset button
Resets the position of the
moved image and the
changed density to return
them to their initial states.
(6) Full preview
All images to be combined
are displayed.
(7)
Part correction
button
Adjusts the density of the
image by pressing [
]
or dragging the bar.
(8)
Move/rotate but-
ton
Moves the position of select-
ed images and adjusts their
angles.
:
image position is moved
toward each direction.
:
image angles are adjusted.
(9)
Magnication Ra-
tio button/Magni-
cation Ratio bar
Display images are magni-
fied/shrunk by pressing
[ ] or dragging the
bar.
(10) Apply button
Applies the adjusted image
combination position.
HINT
•••••••••••••••••••••••••••••••••••••
z
Moving/rotating an image during image
combination
• For image movement/rotation, the lower image is the
operational object. The movement/rotation action is as
follows.
Moving
[ ][ ][ ][ ]:
Moves the image to direction
pressed.
The image can also be moved by
dragging the center of the image
(horizontal stripe portion).
Rotating
[ ]: Lowers the upper left
edge of the image
[
]: Raises the upper left
edge of the image
[
]: Lowers the upper right
edge of the image
[
]: Raises the upper right
edge of the image
If you drag the left or right area of the image (horizontal
stripe portion) vertically, you can move the upper edge
up or down in the direction you are dragging it. If you
drag it horizontally, you can move the image horizon-
tally.
z
Linking 3 images
• When combining 3 images, the lower image will also
move/rotate if the central image is moved/rotated.
To Next Page
