HEADER ATTA CHMEN T/DETACHMENT
Figure 4.80: Gleaner LL Model A lignment Pins
3. Raise feed
er house to lift header ensuring feeder
house sadd
le (A) and alignment pins are properly
engaged in
adapter frame.
4. Raise hea
der slightly off the ground.
DANGER
To avoid bodily injury or death from unexpected
start-up of machine, always stop engine and remove
key from ignition before leaving operator’s seat for
any reason.
5. Stop engine and remove key from ignition.
Figure 4.81: Feeder House and Adapter
6. Engage
lugs (A) with adapter using lock handle (B).
Figure 4.82: Challenger and Massey Ferguson
147695 233 Revision A
