HEADER ATTA CHMEN T/DETACHMENT
9. Retract lugs (A) at base of feeder house with lock
handle (B).
Figure 4.95: Challenger and Massey Ferguson
Figure 4.96: Gleaner R and S Series
10. Lower f
eeder house until saddle (A) disengages and
clears
adapter support.
11. Slowly
back combine away from adapter.
Figure 4.97: Adapter on Combine
147695 239 Revision A
