MAINTENANCE AND SERVICING
• If the indicator range is as shown at right, the wing is
too heavy.
Figure 5.306: Wrench Indicator
12. Place wrench (A) back onto the right-hand adapter leg.
Figure 5.307: Torque Wrench
13. Lock the wings by moving spring handles (A) to upper
LOCK position.
Figure 5.308: Wing Lock in Lock Position
147695 400 Revision A
