5. PARAMETERS
5 - 22
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PA07
*CDV
Electronic
gear
denominator
Set an electronic gear denominator. In the indexer method, set the number of gear
teeth on servo motor side.
Set the value within the range of [Pr. PA06].
This parameter corresponds to "Shaft revolutions (Index: 6091h, Sub: 2)". When this
parameter is mapped for the PDO communication, the value written with Setup
software (MR Configurator2
TM
) is overwritten with the upper side. Thus, do not write
a value with Setup software (MR Configurator2
TM
).
Setting range: 1 to 16777215
1
Set an electronic gear denominator.
Set the value within the range of [Pr. PA06].
This parameter corresponds to "Shaft revolutions (Class ID: 64h, Ins ID: 6091h, Attr
ID: 2)". When this parameter is mapped for the I/O communication, the value written
with Setup software (MR Configurator2
TM
) is overwritten with the upper side. Thus,
do not write a value with Setup software (MR Configurator2
TM
).
Setting range: 1 to 16777215
1
Set an electronic gear denominator. In the indexer method, set the number of gear
teeth on servo motor side.
Set the value within the range of [Pr. PA06].
This parameter corresponds to "Shaft revolutions (PNU: 24721, Sub: 1)". When this
parameter is mapped for the Process Data communication, the value written with
Setup software (MR Configurator2
TM
) is overwritten with the upper side. Thus, do
not write a value with Setup software (MR Configurator2
TM
).
Setting range: 1 to 16777215
1
