SMC Networks LECSN-T Series User Manual

5. PARAMETERS
5 - 30
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PA21
*AOP3
Function
selection A-3
_ _ _ x
One-touch tuning function selection
0: Disabled
1: Enabled
When this digit is "0", the one-touch tuning will be disabled.
1h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
PA22
**PCS
Position
control
composition
selection
_ _ _ x
For manufacturer setting
0h
_ _ x _
Super trace control selection
0: Disabled
2: Enabled
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
Scale measurement function selection
Do not change this value.
0h
PA23
DRAT
Drive
recorder
arbitrary
alarm trigger
setting
_ _ x x
Alarm detail No. setting
Set the digits when you execute the trigger with arbitrary alarm detail No. for the
drive recorder function.
When these digits are "0 0", only the arbitrary alarm No. setting will be enabled.
00h
x x _ _
Alarm No. setting
Set the digits when you execute the trigger with arbitrary alarm No. for the drive
recorder function.
When "0 0" are set, arbitrary alarm trigger of the drive recorder will be disabled.
00h
Setting example:
To activate the drive recorder when [AL. 50 Overload 1] occurs, set "5 0 0 0".
To activate the drive recorder when [AL. 50.3 Thermal overload error 4 during operation] occurs, set "5 0 0 3".
PA24
AOP4
Function
selection A-4
_ _ _ x
Vibration suppression mode selection
0: Standard mode
1: 3 inertia mode
2: Low response mode
When you select the standard mode or low response mode, "Vibration suppression
control 2" is not available.
When you select the 3 inertia mode, the feed forward gain is not available.
Before changing the control mode during the 3 inertia mode or low response mode,
stop the motor.
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
