5. PARAMETERS
5 - 45
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PC03
*ENRS
Encoder
output pulse
selection
_ _ _ x
Encoder output pulse phase selection
Select an encoder pulse direction.
0: Increasing A-phase 90° in CCW or positive direction
1: Increasing A-phase 90° in CW or negative direction
0h
Setting
value
Servo motor rotation direction
CCW or positive direction
CW or negative direction
0
A-phase
B-phase
A-phase
B-phase
1
A-phase
B-phase
A-phase
B-phase
_ _ x _
Encoder output pulse setting selection
0: Output pulse setting
1: Division ratio setting
3: A-phase/B-phase pulse electronic gear setting
4: A/B-phase pulse through output setting
Refer to app. 12 for details.
0h
_ x _ _
Selection of the encoders for encoder output pulse
Do not change this value.
0h
x _ _ _
For manufacturer setting
0h
PC04
**COP1
Function
selection C-1
_ _ _ x
For manufacturer setting
0h
_ _ x _
0h
_ x _ _
0h
x _ _ _
Encoder cable communication method selection
Do not change this value.
0h
