5. PARAMETERS
5 - 48
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Network
ECT
EIP
PNT
PC10
MOD2
Analog
monitor 2
output
_ _ x x
Analog monitor 2 output selection
Select a signal to output to MO2 (Analog monitor 2). Refer to app. 8.3 for detection
point of output selection.
Refer to [Pr. PC09] for settings.
01h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PC11
MO1
Analog
monitor 1
offset
Set the offset voltage of MO1 (Analog monitor 1).
Setting range: -999 to 999
0
[mV]
PC12
MO2
Analog
monitor 2
offset
Set the offset voltage of MO2 (Analog monitor 2).
Setting range: -999 to 999
0
[mV]
PC17
**COP4
Function
selection C-4
_ _ _ x
For manufacturer setting
0h
_ _ x _
Linear scale multipoint Z-phase input function selection
Do not change this value.
0h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PC18
*COP5
Function
selection C-5
_ _ _ x
For manufacturer setting
0h
_ _ x _
1h
_ x _ _
0h
x _ _ _
[AL. E9 Main circuit off warning] selection
Select an occurring condition of [AL. E9 Main circuit off warning].
0: Detection with ready-on and servo-on command
1: Detection with servo-on command
0h
PC19
*COP6
Function
selection C-6
_ _ _ x
[AL. 99 Stroke limit warning] selection
Enable or disable [AL. 99 Stroke limit warning].
0: Enabled
1: Disabled
When "Disabled" is selected, [AL. 99 Stroke limit warning] will not occur while LSP
(Forward rotation stroke end) or LSN (Reverse rotation stroke end) is off, but the
operation will be stopped with the stroke limit.
0h
_ _ x _
For manufacturer setting
0h
_ x _ _
0h
x _ _ _
0h
